8V 65rpm 1500mA Brush Dc Worm Gear Motor 0.4nm Intelligent Lock

Name: 8V 65rpm 1500mA Brush Dc Worm Gear Motor 0.4nm Intelligent Lock
Brand: SECORE
SKU: DC58111-WG
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (134 reviews)

Minimum Order Quantity :	100	Price :	Negotiated The Price
Packaging Details :	100pcs per carton or as request	Delivery Time :	10-12 working days
Payment Terms :	T/T, D/A	Supply Ability :	100000pcs per month

Place of Origin:	Guangdong	Brand Name:	SECORE
Certification:	CE ROHS	Model Number:	DC58111-WG

Detail Information
Rated Speed:	65rpm	Continuous Current:	1500mA
Commutation:	Brush	Voltage:	8V
Rated Torque:	4.4 Kgf.cm	Motor Dimension:	58mm *111mm
Type:	Gear Motor, Brush Dc Worm Gear Motor	Typical Application:	Intelligent Lock, Electric Carbinet, Door Lock, Smart Lock
High Light:	65rpm Brush Dc Worm Gear Motor , 1500mA Brush Dc Worm Gear Motor , Brush Commutated Worm Gearbox Motor

Product Description

8V Brush Dc Worm Gear Motor 4.4 kgf.cm, Intelligent Lock Worm Gearbox 58mm Motor

Main features:

Motor type: Brush commutated DC gear motor
Gearbox type: worm gearbox
Diameter of Gearbox: 58mm*65mm L; DC motor: 45mm L

		No load		load				stall
Model number	Rated voltage	current (mA)	speed (rpm)	current (mA)	speed (rpm)	torque kgf.cm	output power W	Torque kgf.cm	Current mA
DC58111-8-87	8	≤250	80	≤1500	65	4.4	2.8	≥25	≤8000
DC58111-8-100	8	≤250	70	≤1500	56	5	2.3	≥25	≤8000

Gear motor dimensions:

8V 65rpm 1500mA Brush Dc Worm Gear Motor 0.4nm Intelligent Lock 0

Provide motor size, lead requirement, working voltage, no-load conversion, no-load current, load, stall current, etc, TO TAILOR YOUR MOTOR.

Motor solution in Areas of expertise:

telescopic rod motor	AI Motor	Robotic arm motor
massage chair motor	curtain motor	medical robot motor
Embossing machine motor	slow juicer motor	roll door motor
printing machine motor	robot cleaner motor	slide door motor
oven gear motor	door motor	PTZ camera motor
