22.2V 400KV Brushless Motor , Robotics Bldc Motor For Precision Power Tool

Name: 22.2V 400KV Brushless Motor , Robotics Bldc Motor For Precision Power Tool
Brand: SECORE
SKU: BLS-4537
Price: 1.00 USD
Availability: InStock
Rating: 4.7 (179 reviews)

Minimum Order Quantity :	50	Price :	Negotiated The Price
Packaging Details :	100pcs per carton or as request	Delivery Time :	10-12 working days
Payment Terms :	T/T, L/C, D/P	Supply Ability :	13000PCS / month

Place of Origin:	Shenzhen	Brand Name:	SECORE
Certification:	ISO9001, RoHS	Model Number:	BLS-4537

Detail Information
Working Voltage:	22.2V	KV Value:	400KV
Max Current:	30A	Rated Power:	340W
Motor Size:	44.7*35mm	Max Torque:	1.1N.m
Max Power:	900W	Application:	Precision Device, Power Tools, Robotics
High Light:	400KV Brushless Motor , Precision Power Tool Bldc Motor , 22.2V Outer Rotor BLDC Motor

Product Description

22.2V 400KV Brushless Motor Robotics Bldc Motor For Precision Power Tool

Secore outrunner bushless motor 4537 Main parameters for reference:

Model number	VOLTAGE	KV	NO LOAD		AT MAXIMUM EFFICIENCY		Stall		Weight
	Nominal constant	rpm/v	SPEED	CURRENT	POWER	CURRENT	TORQUE	POWER	Weight
	Volts	rpm/v	±10% r/min	mA	w	A	N.m	W	kg
BLS-4537	22.2	400	8880	1330	340	30	1.1	900	0.15
BLS-4537	22.2	330	7330	1100	280	25	0.9	750	0.15

Outline drawing for model BLS-4537 robot motor:

22.2V 400KV Brushless Motor , Robotics Bldc Motor For Precision Power Tool 0

22.2V 400KV Brushless Motor , Robotics Bldc Motor For Precision Power Tool 1
